Chinese Physics C > 2012, Vol. 36 > Issue(3): 235-240 DOI: 10.1088/1674-1137/36/3/008

Suppressing ringing caused by large photomultiplier tube signals

Abstract
HTML
Reference
Related

PDF

Abstract：
We describe here the characteristic features of the ringing we observed following large PMT signals in the Daya Bay reactor antineutrino experiment. We conclude that the ceramic capacitors used in the circuitry of the PMT bases and the HV-signal decouplers are the primary cause for this ringing. We present some possible schemes to reduce the ringing when replacing these ceramic capacitors is not feasible.

References

[1]	Daya Bay collaboration. arXiv:hep-ex/0701029v12 Horowitz P. The Art of Electronics. second edition. Lon- don: Cambridge University Press, 19893 Suchicital C et al. IEEE Comp. Hybrids, Manuf. Techno.1985, 8: 283-288
