Design for the lattice with 4-DBA structure of the compact laser-electron storage ring

YANG Dan-Dan
HUANG Wen-Hui

Received Date:2010-11-04
Accepted Date:1900-01-01
Available Online:2011-08-05

Abstract:We try to design the lattice with 2 super periods and 4-DBA structure in order to provide more drifts for the future development of the TTX source. Due to the space limitation in the lab, the 4-DBA lattice is suitable.In the paper,we present the lattice design with a 4-DBA structure mainly for the pulse mode of the compact laser-electron storage ring (LESR). Element parameters of the lattice are optimized with the help of the professional software and beam dynamics such as intra-beam scattering (IBS) and Compton scattering (CS) are calculated. Besides, the fringe field effect is analyzed with the numerical method.
