Chinese Physics C > 2010, Vol. 34 > Issue(3): 405-408 DOI: 10.1088/1674-1137/34/3/020

Simulation and experiments for theQ_extof a cavity beam position monitor

LI Xiang^,,
ZHENG Shu-Xin

Abstract
HTML
Reference
Related

PDF

Abstract：

The external Q (Q_ext) of the dipole mode is a key parameter of the Cavity Beam Position Monitor (CBPM). It determines the amplitude and length of the dipole mode signal. In this paper, Q_extof a CBPM whose waveguides were open to the air was simulated and measured, and the results agreed with each other. Then four waveguide-to-coaxial cable adpaters were adjusted and assembled to the CBPM, and Q_extremained unchanged. This progress provides a reliable method to evaluate Q_extin the physics design without simulating the structurally complex adapters.
