Chinese Physics C > 2010, Vol. 34 > Issue(3): 402-404 DOI: 10.1088/1674-1137/34/3/019

200 MW S-band traveling wave resonant ring development at IHEP

Abstract
HTML
Reference
Related

PDF

Abstract：

The resonant-ring is a traveling wave circuit, which is used to produce high peak power with comparatively smaller stored energy. The application to be
considered is its use as a high power simulator mainly for testing the klystron ceramic output window, as well as for high power microwave transmission devices. This paper describes the principle of a resonant ring and introduces the structure and property of the newly constructed traveling wave resonant ring at IHEP. Our goal is to produce a 200 MW class resonant ring at 2.856 GHz with a pulse length of 2 μs and repetition rate of 25 Hz. The installation, commissioning and testing of the ring have been completed and a peak power of 200 MW at 3 μs has been achieved. The conditioning results show that all the parameters of the resonant ring reach the design goals.

References

[1]

. JIN K, Holtkamp N. Journal of University of Science and Technology of China, 2000, 30(2): 169-1732. GU M P, LIU J F et al. S-Band Traveling Wave Resonant Ring. 6th Chinese Institute of Vacuum Electronic. 1986 (in Chinese)3. ZHOU Z S, DONG D et al. Atomic Energy Science and Technology, 2008, 42(5): 396-399 (in Chinese)4. Tischer F J. IRE Transactions PGMTT, 1957. MTT 5(1):51-565. Montgomery C G, Dicke R H et al. M.I.T. Rad. Lab. Series,1948, l8: 1496. Miller S J. The Microwave Journal, 1960, 50-58
