Design of a MeV ultra-fast electron diffraction experiment at Tsinghua university

Abstract
HTML
Reference
Related

PDF

Abstract：

Time-resolved MeV ultra-fast electron diffraction (UED) is a powerful tool for structure dynamics studies. In this paper, we present a design of a MeV UED facility based on a photocathode RF gun at Tsinghua University. Electron beam qualities are optimized with numerical simulations, indicating that resolutions of 250 fs and 0.01 AA, and bunch charge exceeding 10⁵electrons are expected with technically achievable machine parameters. Status of experiment preparation is also presented.
