Chinese Physics C > 2009, Vol. 33 > Issue(S2): 105-108 DOI: 10.1088/1674-1137/33/S2/027

Beam dynamics and RF design of trapezoidal IH-RFQ with low energy spread

Abstract
HTML
Reference
Related

PDF

Abstract：

Beam dynamics and RF design have been performed of a new type trapezoidal IH-RFQ operating at 104 MHz for acceleration of¹⁴C⁺in the framework of RFQ based¹⁴C AMS facility at Peking University. Low energy spread RFQ beam dynamics design was approached by the method of internal discrete bunching.¹⁴C⁺will be accelerated from 40 keV to 500 keV with the length of about 1.1 m. The designed transmission efficiency is better than 95% and the energy spread is as low as 0.6%. Combining the beam dynamics design, a trapezoidal IH-RFQ structure was proposed, which can be cooled more easily and has better mechanical performance than traditional RFQ. Electromagnetic field distribution was simulated by using CST Microwave Studio (MWS). The specific shunt impedance and the quality factor were optimized primarily.

References

[1]

. Kapchinsky M, Teplyakov V A. Prib. Tekh. Eksp., 1970,(2): 19|222. Wangler T P. Principles of RF Linear Accelerators. NewYork: John Wiley Sons, 1998. 225-2573. Roberts M L, Hamm R W, Dingley K H et al. Nucl. In-strum. Methods B, 2000, 172(1-4): 262-2674. GUO Zhi-Yu, LIU Ke-Xin, YAN Xue-Qing et al. Nucl. In-strum. Methods B, 2007, 259(1): 204-2075. GUO Zhi-Yu, XIE Yi, LIU Ke-Xin et al. HEP NP, 2006,30(Supp.Ι): 114-116 (in Chinese)6. Staples J W. Proc. of LINAC1994, 7557. Ratzinger U, Kaspar K, Malwitz E et al. Nucl. Instrum.Methods A, 1998, 415: 281-2868. Crandall K R, Stokes R H, Wangler T P et al. Proc. of LINAC1979, BNL-51134, 205-2209. YAN Xue-Qing, FANF Jia-Xun, GUO Zhi-Yu et al. HEP NP, 2006, 30(Supp..): 19-21 (in Chinese)10. YAN Xue-Qing, Jameson R A, LU Yuan-Rong et al. Nucl.Instrum. Methods A, 2007, 577(3): 402-40811. Bricault P G, Schneider H R, Vancouver B C. Proc. of PAC1995, IEEE96, 1125-1127
