Ultra-low emittance X-band photocathode RF gun

TANG Chuan-Xiang^,,
LIU Xiao-Han

Abstract
HTML
Reference
Related

PDF

Abstract：

In this paper, we present the simulation results of a 1.6 cell X-band photocathode RF gun for ultra-low emittance electron beams. It will work at 9.3 GHz. The emittance, bunch length, electron energy and energy spread at the gun exit are optimized at bunch charge of 1pC using PARMELA. Electron bunches with emittance about 0.1 mm·mrad and bunch length less than 100 fs can be obtained from this gun. A PITZ type coupler is adopted in this gun and an initial simulation by MAFIA is also given in this paper.
