Chinese Physics C > 2009, Vol. 33 > Issue(4): 297-300 DOI: 10.1088/1674-1137/33/4/012

A GUI tool for beta function measurement using MATLAB

Abstract
HTML
Reference
Related

PDF

Abstract：

The beta function measurement is used to detect the shift in the betatron tune as the strength of an individual quadrupole magnet is varied. A GUI (graphic user interface) tool for the beta function measurement is developed using the MATLAB program language in the Linux environment, which facilitates the commissioning of the Shanghai Synchrotron Radiation Facility (SSRF) storage ring. In this paper, we describe the design of the application and give some measuring results and discussions about the definition of the measurement. The program has been optimized to solve some restrictions of the AT tracking code. After the correction with LOCO (linear optics from closed orbits), the horizontal and the vertical root mean square values (rms values) can be reduced to 0.12 and 0.10.

References

[1]

www.aps.anl.gov/epics/2 Terebilo A. Accelerator Modeling with MATLAB Acceler-ator Toolbox. In: PAC. Chicago, USA, 2001. 3203-32053 Terebilo A. Channel Access Toolbox for MATLAB. In:ICALEPCS. San Jose, USA, 2001. THAP0304 Robin D, Safranek J, Decking W. Physical Review Special Topics-Accelerators and Beams, 1999, 2: 0440015 Safranek J. Nuclear Instrument and Method in Physics Re-search A, 1997, 388: 276 Zimmerman F. Measurement and correction of acceleratoroptics. SLAC-PUB. 1998, 7844: 217 Bartolini R, Giovannozzi M, Scandale W. Algorithms for a Precise Determination of the Betatron Tune. EPAC. 1996.1329-13318 Laskar J. Introduction to frequency map analysis. PAC. Portland Oregon USA, 2003. 378-3829 Corbett J, Portmann G, Terebilo A. Accelerator Control Middle Layer. PAC. Portland Oregon, USA, 2003. 2369-2371
