Design of a higher harmonic cavity for the SSRF storage ring

Abstract
HTML
Reference
Related

PDF

Abstract：

Higher harmonic cavity used in the third generation synchrotron light source increases the Touschek lifetime. The higher harmonic cavity of Shanghai Synchrotron Radiation Facility (SSRF) is a 1.5GHz passive superconducting cavity. Its higher order modes (HOM) are extracted by a ferrite HOM damper out of the cryostat. Multi-cell cavity is chosen concerning the voltage. The harmonic cavity dynamics, beam dynamics with passive harmonic cavity and the design of single cell cavity are included in this paper.
