Calculation of Coupling Impedance of the Injection Section for the SSRF Storage Ring

Shanghai Institute of Applied Physics, CAS, Shanghai 201800, China2 Graduate School of the Chinese Academy of Sciences, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The longitudinal coupling impedance of the injection section for the SSRF is analyzed in this paper. The main contributions are coated ceramic chambers and the injection tapers. They are treated with the analysis method and numerical method,respectively. The broad band impedance as well as the narrow band impedance of the cavity like structure, which is formed by the two adjacent tapers is calculated. No trapped mode has been found.The broad band impedance is expressed in terms of effective broad band impedance, which is more convenient for microwave instability analysis.
