Chinese Physics C > 2005, Vol. 29 > Issue(8): 770-774

Irradiation Test of FPGA for BES-Ⅲ

Department of Modern Physics, University of Science and Technology of China, Hefei 230026, China2 Department of Nuclear Physics, China Institute of Atomic Energy, Beijing 102413, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The irradiation effect of FPGA, applied in Front-end Electronics for experiments of High-Energy Physics, is a serious problem. The performance of FPGA, used in the front-end card of Muon Counters of BES-III project, needs to be evaluated under irradiation. SEUs on Altera ACEX 1K FPGA, observed in the experiment under the irradiation of γ ray, 14 and 2.5MeV neutrons, was investigated. We calculated involved cross-section and provided reasonable analysis and evaluation for the result of the experiment. The conclusion about feasibility of applying ACEX 1K FPGA in the front-end card of the readout system of Muon Counters for BES-III was given.

References

[1]

. ACEX 1K Programmable Logic Device Family Data Sheet . Altera Corporation2. WANG Tong-Quan , SHENG Yong-Ping , WANG Shang-Wu et al . Journal of National University of Defense Technology ,1999 , 21 (4) : 36 —39(in Chinese)(王同权,沈永平,王尚武等. 国防科技大学学报,1999 , 21 (4) :36 —39)3. HE Chao-Hui , CHEN Xiao-Hua , LI Guo-Zheng. Chinese Journal ofComputational Physics , 2002 , 19(4) : 367 —371 (in Chinese)(贺朝会,陈晓华,李国政. 计算物理,2002 ,19 (4) : 367 —371)4. Karol Bunkowski et al . Radiation Tests of RPC Trigger Electronic Components. RPC Trigger Electronics System Review. Warsaw , 08. 07.2003
