Developing a Special RF Connector for Coaxial Impedance Measurement Platform

Accelerator Laboratory, Department of Engineering Physics, Tsinghua University, Beijing 100084, China2 Institude of High Energy Physics, CAS, Beijing 100039, China

Abstract
HTML
Reference
Related

PDF

Abstract：
This paper introduces the development of a special RF connector used in the Coaxial Impedance Measurement Platform. The connector has good broadband transmission performance while the structure of tightening the inner conductor included. The design is done with 3D simulation code MAFIA, the calculated refelection factor less then 0.1 below 20GHz. The measured refelection factor of the manufactured connector is less then 0.2 below 17GHz.
